Nema 23 with Encoder

Nema 23 Stepper Motor with High Resolution Encoder | Model Number: MT-23**HS**BN | Step Angel: 1.8° | Holding Torque: 175oz.in (12.6kg.cm) | Current / Phase: 2.80A | Frame Size: 57*57mm | Certification: CE, ISO, ROHS
  • Product Desc
  • Product Detail
  • Ask a question

Item
Specifications
Step Angle
1.8°
Step Angle Accuracy
1.8°±5% (full step, no load)
Resistance Accuracy
±10%
Inductance Accuracy
±20%
Temperature Rise
80°C Max.(2 phase on)
Ambient Temperature
-20°C~+50°C
Insulation Class
B, 130°C
Insulation Resistance
100MΩMin. , 500VDC
Shaft Radial Play
0.02Max. (450 g-load)
Shaft Axial Play
0.08Max. (450 g-load)
Max. radial force
28N  (20mm from the flange)
Max. axial force
10N


Model #

Single Shaft

Rated Current

(Amps/Phase)

Holding Torque

(oz.in)

Holding Torque

(kg.cm)

Resistance

(Ohms/Phase)

Inductance

(mH/Phase)

Inertia

(g.cm2)

Detent Torque

(g.cm)

Weight

(kg)

Recommended Voltage

(V DC)

MT-2303HS280BM
2.80 175.0 12.6 0.9 2.5 300 400 0.74 24-48


ENCODER

· Feature

It has 3 square-wave outputs which are 90-degree phase shifted for counting and direction information and one optional index channel.

· Specification

·  Electrical Specifications
Output Wave
Square Wave
Current Consumption
≤60mA
Output Current
0-5mA
Response Frequency 0-100KHz
Output Phase Difference
90°± 45°
Signal Level
Vh≥85%Vcc, VL≤0.3V
·  Mechanical Specifications
Rotor Inertia Of Code-Wheel
6.0x10-8 Kgm2
Shock Resistance
980m/s2, 6ms, 2 times each on XYZ
Vibration Proof
50m/s2, 10-200Hz, 2 hours each on XYZ
Working Life
MTBF≥50000h (+25℃, 2000rpm)
Weight
10g
·  Environmental Specifications
Working Humidity
30-85% (no condensation)
Working Tem.
-25℃-85℃
Storage Tem.
-40℃-85℃
Weld Tem.
≤260℃


· Connection Table

Sinlge Ended (Voltage Output)
0V
Z A Vcc B

Differential (Line Driver Output)
0V
Vcc
A
A/
B B/ Z
Z/

Leads/Wires


Custom service


According to different requirement and application, we provide customized motor.

Common cases:

1)  Special shaft sizes and features, like multiple flat options, helical cut, slotted options, hollow, etc.

2)  Special lead lengths, cables and crimped various connectors

3)  Different pulleys, gears and couplings

4)  Encoders, brakes and integrated drivers

5)  Waterproof and dustproof treatment

6)  High-temperature resistance


If you have any requirement, don’t hesitate to contact us. Our email: sales@motechmotor.com
